WIRELINE VALVE CLOSING UNIT (WLV)

Portable Dual Wireline Valve Closing Unit (WLV) built by The Cypher Company, closing 3 times FASTER than similar models and The Cypher Company’s includes the following listed enhancements:

  • 24”L x 20”W x 23”H plus raised weld-neck fill and splash guard.
  • 2.5 Gallon Accumulator, 3,000 PSI max
  • 38:1 Pump Ratio Air/Hydraulic
  • Max air pressure 75 PSI
  • Max hydraulic pressure 2,850
  • Hydraulic tank reservoir 12 US gallon
  • Recommended for type #46 hydraulic oil
  • Welded raised neck hyd oil fill w/ strainer & lockable cap
  • Splash guard protecting hyd fill neck
  • Center tank cleanout hole
  • Hyd oil sight gauge w/ oil temp
  • 2″ tank sump w/ valve & drain hose
  • 1/2″ air inlet to hyd pump
  • Coalescing ½” air filter – accessible
  • Y-strainer w/ SS screen – hyd pump suction accessible
  • Panel gauge w/ pump pressure
  • Adjustable pressure relief valve w/ dump to tank
  • Actuating hyd valves ported SAE thread
  • Air & hyd – all hose – no steel tubing
  • (Optional) – Tool trap open Adjustable 0-1000 PSI pressure reducer, 0-1500 pressure gauge liquid filled, (1) QD tool trap outlet, 1/4 turn valve to dump tool trap pressure to tank





INDUSTRY LEADER

The Cypher Company provides oil and gas EXPLORATION products to FRACERS AND WIRELINE CONTRACTORS IN eastern regions of the United States.
